The series of energy storage hybrid inverters connect, coordinate, and control photovoltaic systems, energy storage batteries, the power grid, and loads. They provide stable, safe, and clean electrical energy for residential, commercial, and industrial users, meeting energy demands in various scenar…
Send Message Get Price
| Production Model | HJ-IO48123S(E-5) |
| PV Input Date | |
| Max, Input Power | 9000W+9000W |
| MPPT Operating Voltage Range | 125-425V |
| Max.Short Circuit Current | 22A+22A |
| Number of MPPT Trackers | 2 |
| Battery Input Data | |
| Battery Voltage Range | 40-60V |
| Max.Charge/Discharge Current | 200A |
| Battery Type | Li-ion/Lead-acid |
| AC Data | |
| Nominal Power | 12000W |
| Nominal Voltage | 230V |
| Nominal Frequency | 50/60Hz |
| Max.Current | 200A |
| Power Factor | 0.8（leading）~0.8（lagging） |
| Protection | |
| Protection | PV Reverse Polarity Protection，Overcurrent Protection，Surge Protection |
| General Data | |
| Operating Temperature Range | -10~55℃ |
| Cooling | Intelligent air cooling |
| Relative Humidity | 5% to 95% relative humidity (non-condensing) |
| Display | LCD,WIFI+APP |
| Communication | CAN/GPRS/WIFI/Bluetooth/4G/LAN |
| Installation | wall-mounted |
| Dimension (W*D*H) | 450*620*142mm |
| Weight | 23.5kg |
| Certification | |
| Production Certification | IEC62109-1/2,EN61326-1:2013 |
Note: Specifications are subject to change without prior notice for product improvement. Data Sheet
Supports various types of energy storage batteries, such as lead-acid batteries and lithium-ion batteries.
Supports single-phase parallel operation and three-phase pure sine-wave output in parallel units.
The voltage level of 200-240Vac can be selected for single-unit or parallel systems.
Supports two photovoltaic inputs and has the function of tracking the maximum power charging/carrying capacity of two MPPT simultaneously. The MPPT efficiency is up to 99.9%.
